ML-15 Compact Fiber Laser Marking Machine
ML-15 is a 20W auto-focusing compact fiber marking machine with a portable design. Whether in the factory, on the job site, or outdoors, the ML-15 portable laser engraving machine is ideal for precise marking and engraving on a variety of metal materials. Suitable for stainless steel, aluminum alloy, ABS plastic, ceramics, jewelry, hard plastic, gold, silver and other materials. Support LightBurn, SapphireMark.
Key Feature Highlights:
|
Product Parameters |
ML-15 |
|
Machine Material |
Aluminum Alloy |
|
Laser Type |
Fiber Laser Generator |
|
Laser Power |
20 W |
|
Laser Wavelength |
1 064 nm |
|
Engraving Accuracy |
0.001mm Minimum |
|
Maximum Pulse Energy |
0.8 mJ |
|
Frequency Adjustable |
3 0-60k HZ |
|
Printing Method |
High-precision two-dimensional scanning method |
|
Marking Speed |
15000mm/s MAX |
|
Cooling System |
Normal temperature air cooling/aluminum plate heat |
|
Marking Line Type |
Dot matrix and vector all-in-one machine |
|
Reflector Size |
Standard : 6.5mm |
|
Marking Range |
110 mm × 110mm |
|
Positioning Method |
Dual Red Light Positioning |
|
Character Lines |
Any line within the marking range |
|
Font |
Simplified Chinese, English , Arabic numerals, etc. |
|
File Format |
BMP / DXF / HPGL / JPEG / PLT ( PLT .DXF format is |
|
Barcode /QR code |
CODE 39, CODE 1 28, CODE 126, EAN 13, PDF 417, 01 |
|
Power Supply Type |
Plug - in AC 110V~220V |
|
Maximum Power |
﹤200W |
|
Machine Net Weight |
27 IB |
|
Overvoltage Category |
Ⅱ |
|
Adapt To Temperature |
10-42℃ |
|
Ambient Relative Humidity |
30%~80%RH ( no condensation) |
|
Support System |
Windows 7/8/10/11 /IOS/Android |
|
Supported Software |
LightBurn 、 SapphireMark |
Package list:
1 x ML Series Fiber Laser Engraving Machine
1 x Rotating Axis Fixture
1 x USB Flash Drive (Included Software)
1 x Laser Protective Glasses
1 x Power Cord
10 x Engraving Test Card
2 x Engraving Test Paper
1 x Product Manual
Rotary Fixture Marking
Dual Red Light Focus
The intelligent red light fixed focus function makes it easy to adjust focus and quick position.
Markable Materials
Boost All Types of Business
FAQ
ML-15 is suitable for a variety of metal and non-metal materials, including stainless steel, aluminum alloy, ABS plastic, ceramics, jewelry, hard plastic, gold, silver, etc. It is a multi-purpose laser marking machine suitable for various industry needs.
ML-15 is equipped with 20W laser power, providing powerful marking capabilities and capable of handling high-precision marking and engraving tasks, ensuring detailed effects on various materials.
Yes, the ML-15 is equipped with an auto-focus function that can automatically adjust the focus according to different materials and workpiece thicknesses, ensuring precise marking results without manual intervention.
The ML-15 is compact and portable, making it ideal for use in the factory, on the job site, or outdoors. Its portability makes it particularly useful in environments that require frequent movement.
ML-15 supports software such as LightBurn and SapphireMark, making it easy to perform graphic design and marking tasks. Users can choose suitable design software for operation according to their own needs.
